Compliant with EN54-16, the European standard for Voice Alarm Systems, the X-618 is the most credible PAVA solution for public settings. Multiple world-class technologies such as Honeywell’s Advanced System Diagnosis (ASD), SIM loudspeaker line supervision and RiskFree dynamic backup lend robustness to these systems and help keep costs down all the way from early procurement to later maintenance.
.jpg)
X-DCS2000 Digital Integrated System Manager (abbr.DCS) is the basic unit of X-618 Public Address and Voice Alarm System. DCS integrates plentiful functions such as zone expansion, multiple audio sources support, audio file storage, net audio,broadcasting, zone control, monitoring, fault diagnosis etc. With powerful audio matrix structure, X-DCS2000 is capable of bringing value to big infrastructures in terms of saving extension and cabling.
| Model No. | X-DCS2000 |
|---|---|
| Dimension (W x H x D) | 482 mmx88 mm x420mm |
| Backup power supply voltage | DC 21.5V-28.5V |
| Main Power Supply Voltage | AC 100-240V, 50/60Hz |
| Rated Power | 50W |
| Packing Dimension (W×H×D) | 580mmx235mm x552mm |
| Gross Weight | 12.5Kg |
| Main Power Supply Fuse | T2AL250V |
| Auxiliary input Frequency response | 60Hz-16KHz (local input signal) |
| Auxiliary Input SNR | >85dB |
| Loudspeaker Circuit Channels | 8 (with circuit fault detection) |
| Audio Output Channels | 8 channels main power amplifier, 2 channels standby power amplifier, 2 channels auxiliary output |
| Audio Output signal | 1.2V(<1.6dBV) |
| Audio Output THD | <0.06% |
| Contact Inputs | 8(with circuit fault detection) |
| Contact Outputs | 8 outputs (NO, NC and COM) |
| Auxiliary input Channels | 3 |
| Auxiliary Input impedance | 10KΩ |
| DCL Inputs Channels | 8 |
| DCL Module Number | 5 modules per channel |
| DCL Module Type | Noise Detector, EOL module |
| Loudspeaker circuit Output Voltage | 100V |
| Memory Capacity | 1 GB (606MB for audio files) |
| Loudspeaker circuit Max. Output load power | 500W |
| Humidity | <95%, without condensing |
| Maximum voltage of the outputs | 250V AC / 30V DC |
| Storage Temperature | -40 °C ~ +70 °C |
| Maximum current of the outputs | 2.5A |
| Ethernet interface | 10M/100M |
| Net Weight | 9.3Kg |
| Ethernet switching | 4 ports |
| Working temperature | -10 °C ~ +55 °C |
| Auxiliary input | AUX1 : 0dBV ( 1V) AUX2: 3: -40dBV-0dBV |
| Audio Output Record output | 1V(0dBV) |
| Monitoring Loudspeaker | 10W/8Ω |
